How to generate hook-up drawings in SmartPlant instrumentation?

SmartPlant Instrumentation Tutorial 379 f Working with Hook-Ups Generate an Enhanced Hook-Up Drawing 1. In the Domain Explorer, in the Hook-Ups folder, right-click the Control Valve hook-up, and then, on the shortcut menu, click Reports > Generate Hook-Up Drawings.

How do I log in to SmartPlant instrumentation?

On the Windows Start menu, click Programs > Intergraph SmartPlant Instrumentation > Administration. 2. On the Logon Information dialog box, type DOMAIN in both the user name and password boxes. 26 SmartPlant Instrumentation Tutorial f Administration Tasks 3.

How to create panel and cable wiring in SmartPlant?

Understanding Concepts and Presentation of Panel and Cable Wiring You can create all your panel and cable wiring from the Domain Explorer, which opens automatically after starting SmartPlant Instrumentation. If for some reason the Domain Explorer is not running, press F7 to open it.

How does SmartPlant instrumentation arrange the wiring items in the domain explorer?

Let us now examine how SmartPlant Instrumentation arranges the wiring items in the Domain Explorer. Panels and their sub-items are arranged in the tree view of the Domain Explorer according to panel location and panel category.

How do I create an instrument in SmartPlant?

On the module toolbar, click Instrument . SmartPlant Instrumentation Tutorial 119 f Defining Process Data 2. On the Enter Tag Number dialog box, type the instrument tag number 101-FE -100 and click OK. Use the Tab key to move the cursor to the character separators.

How do I enable enhanced hook-up drawing in SmartPlant instrumentation?

Set Preferences for Enhanced Hook-Up Drawings 1. Click File > Preferences. 2. On the Preferences > General page ensure that you have defined the SmartPlant Instrumentation temporary folder path. SmartPlant Instrumentation Tutorial 359 f Working with Hook-Ups 3.

How to generate loop drawings in SmartPlant?

Right-click, and on the shortcut menu, click Reports > Generate Loop Drawings to generate the reports for both loops. 316 SmartPlant Instrumentation Tutorial f Generating Loop Drawings 13. In the Enhanced Report Utility, view each report by selecting it from the Window menu.

How to generate enhanced report in SmartPlant instrumentation?

SmartPlant Instrumentation Tutorial 359 f Working with Hook-Ups 3. On the Hook-Ups > General page, under Default generation method, select Enhanced Report. 360 SmartPlant Instrumentation Tutorial f Working with Hook-Ups 4.

How to initialize a domain in SmartPlant instrumentation?

SmartPlant Instrumentation Tutorial 19 f Administration Tasks Initialize a Domain 1. Click File > Initialize. 2. On the Initialize dialog box, enter data as shown.  Ensure that in the Target domain type group box, you select Engineering company.  You may enter your own domain and schema names if you wish.

How to create instrumentation in SmartPlant instrumentation 53?

SmartPlant Instrumentation Tutorial 53 f Creating Instruments and Control Loops 3. On the Instrument Types dialog box, from the Process function list, select Flow. 4. Create a new instrument type as follows: a. Click New to add a new row. b. Type the instrument type name FE.

How to create panel and cable wiring in SmartPlant?

Understanding Concepts and Presentation of Panel and Cable Wiring You can create all your panel and cable wiring from the Domain Explorer, which opens automatically after starting SmartPlant Instrumentation. If for some reason the Domain Explorer is not running, press F7 to open it.

What are the Select lists in the SmartPlant instrumentation interface?

These select lists appear in the database in supporting tables. In the SmartPlant Instrumentation interface, supporting tables are represented by dialog boxes that allow you to create, delete, and edit various properties that apply to SmartPlant Instrumentation loops or instrument tags. Create a P&ID Drawing Document Number 1.
